PTFEW Temperature sensor
Accessories and Thermometric Sensors
Product Description
Pt100 sensor suitable to detect the temperature of the coils of MV-MV, MV-HV transformers.
- PTFEW 30 KV
- RTD Pt100 Pt100 ohm at 0°C
- Calibration: IEC 60751
- Round Ø 10 x 120 mm
- Cable PFA 3 x 0,36 mm² insulated
- Standard cable length: 2,5 mt (different lenghts on request)
- Dielectric strength: 30 kVac – 60”
- Max. operating temp.: 220°C
